The LT1013’s specifications are similar to (even somewhat better than) the LT1014’s.īoth the LT1013 and LT1014 can be operated off a single 5V power supply: input common mode range includes ground the output can also swing to within a few millivolts of ground. Similarly, the LT1013 is the first precision dual op amp in the 8-pin industry standard configuration, upgrading the performance of such popular devices as the MC1458/MC1558, LM158 and OP-221. Although supply current is only 350μA per amplifier, a new output stage design sources and sinks in excess of 20mA of load current, while retaining high voltage gain. Particularly important is the low offset voltage, since no offset null terminals are provided in the quad configuration.
The LT1014’s low offset voltage of 50μV, drift of 0.3μV/☌, offset current of 0.15nA, gain of 8 million, common mode rejection of 117dB and power supply rejection of 120dB qualify it as four truly precision operational amplifiers. It is no longer necessary to compromise specifications, while saving board space and cost, as compared to single operational amplifiers. *This information is for general informational purposes only, we will not be liable for any loss or damage caused by the above information.The LT1014 is the first precision quad operational amplifier which directly upgrades designs in the industry standard 14-pin DIP LM324/LM348/OP-11/4156 pin configuration. The company offers a wide range of products including microcontrollers, sensors, power amplifiers, and integrated circuits for various applications in the automotive, industrial, and consumer markets.įounded in 1987, STMicroelectronics has operations in over 100 countries and is one of the largest semiconductor companies in the world. STMicroelectronics is a multinational electronics and semiconductor manufacturer based in Geneva, Switzerland.
